KSOURCEEP Ceramic Structured Packing for shipment
Created date: 2020-09-15
Ceramic Structured Packing for export:

Our products Ceramic Structured Packing with top quality, the material of ceramic with excellent resistance with various kinds of organic acid & inorganic acid except HF acid.  And can be used in high or low temperature.

Structured Packing because of its uniform and symmetric, stipulated flow path, it has the advantages of compression, large flux, and high separation efficiency.



Applications:

Fine Chemicals

Petrochemicals

Fertilizer

Distillation of halogenated organic compounds

The rectification and absorption processes of corrosive mixtures with strict pressure drop and theoretical number of plates.

Sulfuric acid absorption, nitric acid enrichment, and gas purification of chemical fertilizer plants, etc., which have a large number of intrinsic media.

Vacuum operation up to 100Pa absolute pressure.

Used as heat exchanger, mist eliminator or catalyst carrier.



Ceramic Structured Packing- (5).jpg




Chemical Analysis

Composition

Value

SiO2

≥72%

Fe2O3

≤0.5%

CaO

≤1.0%

Al2O3

≥23%

MgO

≤1.0%

Other

2%



Physical Property

Index

Value

Specific gravity(g/cm3)

2.5

Water absorption (wt%)

≤0.5

Acid resistance (wt%)

≥99.5

Loss in burn (wt%)

≤5.0

Max. Operating Temp.(℃)

800

Crush strength (Mpa)

≥130

Moh’s Hardness(Scale)

≥7



Ceramic Structured Packing- (2).jpg


Technical Data

Spec.

Specific surface

(m2/m3)

Bulk density

(kg/ m3)

Void ratio

(%)

Obl. Angle

Pressure drop

(mm Hg/m)

Theo. Plate

(m-1)

Hydraulic diameter

(mm)

Liquid load (m3/m2h)

Max. Factor

m/s (Kg/m3)-1

125Y

125

320

90

45

1.8

1.8

28

0.2-100

3.0

250Y

250

420

80

45

2

2.5

12

0.2-100

2.6

350Y

350

470

78

45

2.5

2.8

10

0.2-100

2.5

450Y

450

520

72

45

4

4

7

0.2-100

1.8

550Y

550

620

74

45

5.5

5-6

6

0.18-100

1.4

700Y

700

650

72

45

6

7

5

0.15-100

1.3



Ceramic Structured Packing- (1).jpg

Ceramic Structured Packing- (9).jpg

We warmly welcome you to send us enquiry for Ceramic Structured Packing !

Tel/ WhatsApp:+8618279964287
